AEDASS-L-203
Sturdy body with a heavy horse hose base inclinable from 1-90 degree tube lenght 160 mm square stage 110x110mm. Coarse and fine movement. Turret dust proff tirplic nose piece with a click stop. Stop arrangement against breakage of slides complete with Huygenian eye pieces 10x and 15x objective 10x45 (S.L.) to total magnification 100x 60x 675x in cabinet with lock and keys with Iris diaphragm.
AEDASS-L-204
Sturdy body with a heavy horse hose base inclinable from 1-90 degree tube lenght 160 mm square stage 110x110mm. Coarse and fine movement. Turret dust prof tirplic nose piece with a click stop. Stop arrangement against breakage of slides complete with Huygenian eye pieces 10x and 15x objective 10x45 (S.L.) to total magnification 100x 60x 675x in cabinet with lock and keys with fixed condenser NA 1.25, Iris diaphragm and filter holder.
AEDASS-L-301
Sturdy body with a heavy horse hose base inclinable from 1-90 degree tube lenght 160 mm square stage 110x110mm. Coarse and fine movement. Turret dust prof tirplic nose piece with a click stop. Stop arrangement against breakage of slides with Rack and pinion motion of condenser unit N.A. 1.25 complete with eye piece Huygenian 10x, 15x Objective 10x and 45x (S.L.) housed in a plywood cabinet with lock and keys.
AEDASS-L-501
With Quadruple Revolving nose-piece, detachable graduated mechanical stage. Coarse motion with sensitive fine focusing reading to 0.002mm and rack and pinion motion of condenser unit N.A. 1.25 with iris diaphragm fixed square stage measuring 120x120 mm built in base illumination system 6v-20w and 220v/AC.
● Provided with Plano concave reflecting mirror for day light use.
● OPTICAL COMBINATION : Eye Piece 10x, 5x Objectives 10x, 45 x (S.L.) 100 x (S.L.)
AEDASS-L-502
Same as Model No. AEDASS-L-501 but with superior quality optics, built in base Halogen illumination system 6v-20w and SOLID STATE built in transformer for use on 220V/AC.
● Provided with plano concave reflecting mirror for day light use.
● OPTICAL COMBINATION : Eye Piece 10x, 5x Objectives 10x, 45 x (S.L.) 100 x (S.L.) with Imported Objective.
AEDASS-L-602
Same as Model No. AEDASS-L-502 but with extra superior quality optics and Binocular head with pair of 10x, 5x Huygenian eye piece with Imported Objective.
AEDASS-L-603
Same as Model No. AEDASS-L-502 but with apir of 10x wide field eye pieces, 5x Huygenian and built in co-axial mechanical stage with Imported Objective.
AEDASS-L-604
Same as Model No. AEDASS-L-603 but with apir of 10x wide field eye pieces, 5x Huygenian and built in co-axial mechanical stage. Illumination is by 6v 20w halogen lamp operated through built in solid state transformer with electric regulator with Imported Objective.
AEDASS-L-701
Sturdy body with trinocular head inclined at 45” ratable through 360 degree with ball bearing quadruple nose piece having positive click stop. Ball bearing, guide-ways in, slide insure highly sensitive focusing system and co-axial focusing system provides highest degree of working, convenience. Bright field abbe condenser 1.25 NA with Irish diaphragm and swing out filter holder moveable by rack and pinion and built in co-axial mechanical stage graduated on both sides. Illumination is by 6 volt 20 watt halogen lamp operated through built in solid state transformer with electric regulator.
With Imported Objective.
